Orbital Machines - Pedestal

P-500 P-750 P-840 P-1000 P-1500

Specifications: Based on mild steel rivets

Head Forming Capacity: .500" (12.7mm)
Max Stroke: 2.5" (63.5mm)
Max Thrust: 4400 lbs @ 100 psi
Weight: 850 lbs
Saddle Range: 36.0-48.0" (914.4-1219.2mm)
Width: 36.0" (914.4mm)
Depth: 32.0" (813.0mm)
Throat Depth: 9.0" (228.6mm)
Height: 82.0" (2083.0mm)

Options:

  • Servo Adjustable Hard Stop: Automatically set the stroke length with a servo and adjust stroke between cycles
  • Offset Motor Mount: Automatically set the stroke length with a servo and adjust stroke between cycles
  • Clutch Brake: Stop the spindle from spinning without shutting down the powerhead motor
  • Gear Reducer: Finely tune your powerhead speed to better control the process
  • Programmable Height Sensing Pressure Pad: Work with other process monitoring to provide precision when compressing stacked parts
  • LVDT Stroke Monitoring: Monitor stroke distance and increase precision and consistent head forming
  • Anti-Rotate Device: Keep the peen from rotating
  • Loadcell Force Monitoring: Force readouts and process optimization
  • Remote Stroke Adjust: Allows for access to the stroke adjust knob when the standard location is difficult to reach
  • Through Spindle Pressure Pad for Roller Heads: Compress part prior to forming to ensure proper assembly and maintain consistency

Specifications: Based on mild steel rivets

Head Forming Capacity: .750" (19.1mm)
Max Stroke: 2.5" (63.5mm)
Max Thrust: 7510 lbs @ 100 psi
Weight: 950 lbs
Saddle Range: 36.0-48.0" (914.4-1219.2mm)
Width: 36.0" (914.4mm)
Depth: 32.0" (813.0mm)
Throat Depth: 9.0" (228.6mm)
Height: 87.0" (2210.0mm)

Options:

  • Servo Adjustable Hard Stop: Automatically set the stroke length with a servo and adjust stroke between cycles
  • Offset Motor Mount: Automatically set the stroke length with a servo and adjust stroke between cycles
  • Clutch Brake: Stop the spindle from spinning without shutting down the powerhead motor
  • Gear Reducer: Finely tune your powerhead speed to better control the process
  • Programmable Height Sensing Pressure Pad: Work with other process monitoring to provide precision when compressing stacked parts
  • LVDT Stroke Monitoring: Monitor stroke distance and increase precision and consistent head forming
  • Anti-Rotate Device: Keep the peen from rotating
  • Loadcell Force Monitoring: Force readouts and process optimization
  • Remote Stroke Adjust: Allows for access to the stroke adjust knob when the standard location is difficult to reach
  • Through Spindle Pressure Pad for Roller Heads: Compress part prior to forming to ensure proper assembly and maintain consistency

Specifications: Based on mild steel rivets

Head Forming Capacity: .840" (21.3mm)
Max Stroke: 2.5" (63.5mm)
Max Thrust: 12,500 lbs @ 100 psi
Weight: 1200 lbs
Saddle Range: 36.0-48.0" (914.4-1219.2mm)
Width: 36.0" (914.4mm)
Depth: 33.0" (838.2mm)
Throat Depth: 9.0" (228.6mm)
Height: 87.0" (2210.0mm)

Options:

  • Servo Adjustable Hard Stop: Automatically set the stroke length with a servo and adjust stroke between cycles
  • Offset Motor Mount: Automatically set the stroke length with a servo and adjust stroke between cycles
  • Clutch Brake: Stop the spindle from spinning without shutting down the powerhead motor
  • Gear Reducer: Finely tune your powerhead speed to better control the process
  • Programmable Height Sensing Pressure Pad: Work with other process monitoring to provide precision when compressing stacked parts
  • LVDT Stroke Monitoring: Monitor stroke distance and increase precision and consistent head forming
  • Anti-Rotate Device: Keep the peen from rotating
  • Loadcell Force Monitoring: Force readouts and process optimization
  • Remote Stroke Adjust: Allows for access to the stroke adjust knob when the standard location is difficult to reach
  • Through Spindle Pressure Pad for Roller Heads: Compress part prior to forming to ensure proper assembly and maintain consistency

Specifications: Based on mild steel rivets

Head Forming Capacity: 1.0" (25.4mm)
Max Stroke: 2.5" (63.5mm)
Max Thrust: 18,000 lbs @ 1000 psi
Weight: 1150 lbs (521.6 kg)
Saddle Range: 36.0-48.0" (914.4-1219.2mm)
Width: 36.0" (914.4mm)
Depth: 48.0" (1219.2mm)
Throat Depth: 9.0" (228.56mm)
Height: 92.0" (2337.0mm)
Please contact your local RSM for machine drawings.

Options:

  • Servo Adjustable Hard Stop: Automatically set the stroke length with a servo and adjust stroke between cycles
  • Offset Motor Mount: Automatically set the stroke length with a servo and adjust stroke between cycles
  • Clutch Brake: Stop the spindle from spinning without shutting down the powerhead motor
  • Gear Reducer: Finely tune your powerhead speed to better control the process
  • Programmable Height Sensing Pressure Pad: Work with other process monitoring to provide precision when compressing stacked parts
  • LVDT Stroke Monitoring: Monitor stroke distance and increase precision and consistent head forming
  • Anti-Rotate Device: Keep the peen from rotating
  • Loadcell Force Monitoring: Force readouts and process optimization
  • Remote Stroke Adjust: Allows for access to the stroke adjust knob when the standard location is difficult to reach
  • Through Spindle Pressure Pad for Roller Heads: Compress part prior to forming to ensure proper assembly and maintain consistency

Specifications: Based on mild steel rivets

Head Forming Capacity: 1.5" (38.0mm)
Max Stroke: 3.0" (76.2mm)
Max Thrust: 38,500 lbs @ 1000 psi
Weight: 1500 lbs (680.4 kg)
Saddle Range: 36.0-48.0" (914.4-1219.2mm)
Width: 46.0" (1168.4mm)
Depth: 64.0" (1625mm)
Throat Depth: 10.0" (254mm)
Height: 104.0" (2641.6mm)
Please contact your local RSM for machine drawings.

Options:

  • Servo Adjustable Hard Stop: Automatically set the stroke length with a servo and adjust stroke between cycles
  • Offset Motor Mount: Automatically set the stroke length with a servo and adjust stroke between cycles
  • Clutch Brake: Stop the spindle from spinning without shutting down the powerhead motor
  • Gear Reducer: Finely tune your powerhead speed to better control the process
  • Programmable Height Sensing Pressure Pad: Work with other process monitoring to provide precision when compressing stacked parts
  • LVDT Stroke Monitoring: Monitor stroke distance and increase precision and consistent head forming
  • Anti-Rotate Device: Keep the peen from rotating
  • Loadcell Force Monitoring: Force readouts and process optimization
  • Remote Stroke Adjust: Allows for access to the stroke adjust knob when the standard location is difficult to reach
  • Through Spindle Pressure Pad for Roller Heads: Compress part prior to forming to ensure proper assembly and maintain consistency
