Standard Products

Orbital Heads - Gold Series

Gold Series heads are heavy duty and provide a greater thrust capacity in a small package. Upgraded sealed bearing configurations give it increased capacity compared to the standard orbital heads. Orbitform Gold Series heads are excellent for forming harder materials, and will not wear out from extended use.

GS-330 GS-520 GS-720

Specifications:

Capacity:	.5" (12.7mm)
Peen Diameter:	.375" (9.525mm)
Peen Angle:	6°
Peen Length:	5" (12.7mm)

Specifications:

Capacity:	.625" (12.875mm)
Peen Diameter:	.5" (12.7mm)
Peen Angle:	6°
Peen Length:	5" (127.0mm)

Specifications:

Capacity:	.75" (19.05mm)
Peen Diameter:	.75" (19.05mm)
Peen Angle:	6°
Peen Length:	7.5" (190.5mm)
